Ekinex keystone front cover 55x55 for 2 connectors EK-KSC-2K
Ekinex keystone front cover 55x55 for 2 connectors EK-KSC-2K
Keystone front cover 55 × 55 mm for two keystone connectors in the FF, 71, 20venti and Signum series. It takes standard Ekinex keystone modules and sits in any plate with a 55 × 55 mm window, next to pushbuttons and sockets of the same finish. Raw white is unpainted technopolymer; the other finishes are painted (the metal, Metal HT and Fenix NTM® colour effects are obtained by painting).
- Size: 55 × 55 mm
- Connectors: 2 keystone modules (the double USB-C module EK-KSM-2USBC-BL is not available for the 2-connector configuration)
- Finishes: raw white (unpainted); painted technopolymer Pure White RAL 9016, Warm White, Intense Black RAL 9005, Silver; metal Aluminium, Nickel, Titanium, Carbon, Brass 26; Metal HT Chrome, Black Metal, Champagne; Fenix NTM White Malè, Beige Luxor, Beaver Ottawa, Grey Ephesus, Grey London, Grey Bromine, Green Commodore, Cocoa Orinoco, Black Ingo
- Mounting: round or square wall box with 60 mm fixing holes, or round boxes combinable at 71 mm spacing
- Manufacturer reference: EK-KSC-2K, EK-KSC-2K-_ (finish code suffix)
Sold separately, required for installation: up to two keystone connectors (RJ45, HDMI, TV-SAT F, TV IEC or blanking plug modules), a plate with 55 × 55 mm window ('NF/Form EK-PQG, Deep EK-DQG or Surface EK-SQG; 2-fold EK-P2G/EK-P2P, EK-D2G/EK-D2P, EK-S2G/EK-S2P; 3-fold EK-D3G/EK-D3P) and the matching plastic adapter (EK-TAQE-1 / EK-TAQE-1-NF for square plates, EK-TAS-Q for Surface plates; 2-fold EK-A71E / EK-TAS-D; 3-fold EK-B71-1-NF); for the Form look a square Form frame EK-FOQ (2-fold: EK-FO2).
