Ekinex EK-EZ2-TP-1 – finished look (rockers and frame sold separately)

Ekinex Proxima KNX pushbutton with thermostat, RGB LED EK-EZ2-TP

1 rocker
€169,70€205,34
excl. VATincl. VAT
Skip to product information
Ekinex EK-EZ2-TP-1 – finished look (rockers and frame sold separately)

Ekinex Proxima KNX pushbutton with thermostat, RGB LED EK-EZ2-TP

€169,70€205,34
excl. VATincl. VAT
Rockers
Delivery in 5–14 business days Shipping policy
Needed for installation (10)

Frames, rockers and adapters are sold separately — choose the finish and add to cart.

  • Ekinex Proxima round rockers Ø 11 mm EK-TTP
    €22,00€26,62
  • Ekinex Proxima square magnetic plate for pushbutton EK-PQA
    €73,80€89,30
  • Ekinex Proxima 2-fold magnetic plate for 2x 4-rocker pushbuttons EK-P2A-44
    €93,00€112,53
  • Ekinex Proxima 2-fold magnetic plate for 2-rocker pushbutton + Schuko/FR/IL socket EK-P2A-2T
    €115,90€140,24
  • Ekinex Proxima 2-fold magnetic plate for 2-rocker pushbutton + 45x45 window EK-P2A-2P
    €115,90€140,24
  • Ekinex Proxima 2-fold magnetic plate for 4-rocker pushbutton + Schuko/FR/IL socket EK-P2A-4T
    €115,90€140,24
  • Ekinex Proxima 2-fold magnetic plate for 4-rocker pushbutton + 45x45 window EK-P2A-4P
    €115,90€140,24
  • €9,80€11,86
  • €3,80€4,60
  • Ekinex round flush-mounting box for movable walls (7-40 mm)
    €1,90€2,30

Ekinex Proxima KNX pushbutton with 1, 2 or 4 round buttons, an RGB LED on each button and an integrated temperature sensor with room thermostat function. It switches and dims lights, moves blinds and runs other KNX functions with separate short/long press actions; the Proxima plate is held magnetically for a clean, screwless look.

  • Buttons: 1, 2 or 4 (select the version); 4-button version: up to 8 functions
  • LEDs: one freely programmable RGB LED per button
  • Sensor: integrated temperature sensor, room temperature controller function
  • Power supply: 30 V DC from the KNX bus, current consumption < 15 mA (typical)
  • Dimensions: 50.5 x 50.5 x 37.5 mm (pushbutton body only), 64 g
  • Mounting: flush-mounted on a round or square box with the EK-SMP-71-1 bracket (sold separately)
  • Operating temperature: -5 … +45 °C, IP20 (installed)
  • In the box: KNX bus terminal and fixing screws
  • Configuration: ETS5 or later (application APEKEZ2TP)
  • Manufacturer reference: EK-EZ2-TP-1 / EK-EZ2-TP-2 / EK-EZ2-TP-4

Sold separately, required for installation: round rockers EK-TTP-1 / EK-TTP-2 / EK-TTP-4 (same number of buttons as the device), a magnetic plate EK-PQA-1 / -2 / -4 (or a 2-gang plate: EK-P2A-44, EK-P2A-2T / 2P, EK-P2A-4T / 4P) and the mounting bracket EK-SMP-71-1; round boxes may need the spacer EK-SMP-Q-1 (not needed with EK-SI2-1T-W / EK-SIT-1D-D boxes).

Official Ekinex product page
